HALO LIFTS 2 Post 10,000 Lb Capacity ALI Certified Lift *** IN STOCK ***
INTRODUCTION THE LATEST ADDITION TO THE HALO LIFTS BRAND
THE HALO LIFTS 2 POST-ALI-CERTIFIED LIFT
Features
• 10,000lbs capacity.
• Dual hydraulic direct-drive cylinders made on high standard.
• Aero cable used for synchronization.
• Single-point manual safety release mechanism, disengages both columns simultaneously from one side.
• Self-lubricating UHMW Polyethylene sliders.
• Clear-floor design, provide unobstructed floor use.
• Overhead safety shut-off device prevents vehicle damage.
• Stackable rubber pads and 1.5”, 3”, 5” adapters as standard supply.
• Standard two height settings accommodate varying ceiling heights.
• Toe guards and tool trays come as standard.
Specifications | ||
Model | HL2C-ALIX and HL2C-ALIXOH This Model |
|
Manual |
MANUAL |
|
Certificate | ALI Certified | |
Lock Release | Single Point Release | |
Warranty | 2 YEAR | |
Lifting Capacity | 10,000 LB | |
Overall Height | 143 3/4" (HL2C-ALIX) 166" (HL2C-ALIXOH) HEIGHT EXTENSION |
|
Overall Width | 140 7/16" (narrow spacing) 146 3/8" (medium spacing) 152 1/4" (wide spacing) |
|
Maximum Lift height with Truck Adapters | 78" | |
Maximum Lift height without Truck Adapters | 69" | |
Minimum Height of Adjustable Pads from Ground | 4" | |
Drive Through Width (Carriage to Carriage) | 88 1/8" (narrow spacing) 94 1/16" (medium spacing) 100" (wide spacing) |
|
Column to Column Width | 97 1/8" (narrow spacing) 103 1/16" (medium spacing) 109" (wide spacing) |
|
Driving Mode | Direct Drive | |
Motor |
220V Single Phase 3HP 10A (recommend a 30A breaker)
|
|
Time to full rise | 50 seconds | |
Hydraulic Oil | 3-5 gallons AW32/AW46 (not included) | |
Truck Adapters | 3 sets: 1 1/2", 3", and 6" tall | |
Front Arms | 3 Stage reach from 19 5/16" to 41 7/8" | |
Back Arms | 3 Stage reach from 37 5/16" to 60 3/16" | |
Column Steel Thickness | 1/4" | |
Carriage Steel Thickness | 1/4" | |
Carriage Yoke Thickness | 9/16" | |
Arm Steel Thickness | 1/4" | |
Base Plate Steel Thickness | 13/16" | |
Shipping Weight |
2000 LB and 200 LB (2 ft height extension for HL2C-ALIXOH)
|
|
Shipping package size |
142"L x 22"W x 38"H and 30"L x 17"W x 17"H ( HL2C-10K-ALIXOH)
|
|
Concrete Requirement | 6" thick at 3500 psi reinforced with fiberglass or steel (4" thick for vehicles 9000LB and below) | |
Model | HL2C-ALIX |
- You will need to have a forklift, a high-capacity hoist, or a tractor in your facility to unload the Lifts from the Freight Truck
- The most popular 2-post lifts (with 9,000 lb and 10,000 lb capacity) have a shipping weight of approximately 1,400 lbs and 1,900 lbs, respectively.
- Given the packaged lift and hydraulic power unit’s weight, they cannot be unloaded from the trailer by hand. Simply put, IT IS MANDATORY TO USE A SUITABLE FORKLIFT OR HOIST FOR UNLOADING THE LIFT.
- You are solely responsible for unloading your equipment from the truck. The truck driver cannot do this for you.
- We use trustworthy freight companies to make the deliveries. It is your responsibility to be present on the scheduled date and time of the delivery.
- There will be a receiver charge of $135 if the truck driver arrives at the designated location and the customer does not have the necessary means ready to unload the lift.
- In case you do not have the necessary equipment to unload the equipment do not worry. We offers other delivery options such as a local pick up or shipping directly to a professional installer.
RETURNS
ALL SALES ARE FINAL ONCE YOUR AUTO EQUIPMENT HAS SHIPPED. Orders canceled after payment is processed but before shipment, will be charged a 5% cancellation fee of the total invoice.
If a product is shipped and purchaser/customer refuses product then customer/purchaser will be responsible for shipping costs both ways and a 30% restock fee.
We do not accept returns once a customer has received and signed for a shipment. Pictures on site are for display purposes only and may not represent exact design of equipment.
Customer is responsible for all charges associated with returning equipment, including but no limited to fork lift or loading equipment needed to put product on freight truck, costs associated with returning equipment to authorized freight terminal, packaging equipment in a manner sufficient for shipping on freight truck.
There is no compensation for cost of time or packaging materials needed to return product.
CANCELLATIONSIf you cancel your order before it has shipped via LTL, you, the customer are responsible for a 5% cancellation fee.
Shipping Damage & Warranty For defective or damaged products, please contact us at the customer service number below.
QUESTIONSIf you have any questions concerning our return policy, please contact us at Info@halocarlifs.com
